Features and uses:
Product Features
● Under the high-speed drive of the motor, a plurality of plungers drive the respective diaphragms to reciprocate in sequence, and the high-frequency movement of the diaphragm makes the pump pulsation smooth to a level that can be ignored.
● HY series maximum output pressure up to 10Mpa, HYH series of maximum output pressure up to 17Mpa. Pump efficiency up to 85%;
● This product has a certain degree of quantitative, by adjusting the motor speed can achieve adjustment of the pump flow.
● HY series is suction pressure 17Mpa, HYH series suction pressure 34Mpa, suitable for conveying easy to start gas such as LPG.
● pump body, valve components, diaphragm materials are available in a variety of complex applications.
Product usage
●Applicable media
Suitable for conveying all kinds of pure liquid, dairy beverages, oils, alcohols, solvents, chemical liquids, chemical fertilizers, corrosive or abrasive pulp, liquefied gases, high viscosity liquids, coatings, fine Particulate liquid or recovery liquid, etc.
●Applicable equipment
Suitable for high pressure filtration equipment, high pressure separation equipment, high pressure cleaning equipment, high pressure water cutting equipment, seawater desalination and reverse osmosis equipment, oil and gas field pressure water injection equipment, spray drying equipment, pesticide joint spraying machinery, fire fighting equipment , shipborne or vehicle liquid conveying equipment, steel plant spraying equipment, grinding machine saponification liquid conveying and recycling equipment, liquefied gas filling equipment, high pressure boiler, flue desulfurization equipment, ceramic or cemented carbide abrasive slurry conveying equipment, animals And poultry housing cleaning and spraying equipment, meat and poultry fish food processing equipment.

Performance curve:
